Please refer to the Pneumatic Manual for techni-
cal specifications on the pneumatic components
and the valves.
Field bus
Design RS 485, floating
Transmission type serial
asynchronous,
half-duplex
Protocols PROFIBUS-DP
Baud rate
9.6 kBaud
19.2 kBaud
93.75 kBaud
187.5 kBaud
500 kBaud
1500 kBaud
3000 kBaud
6000 kBaud
12000 kBaud
Cable length
(dependent on baud rate
and cable type)
up to 23.8 km
Cable type
(dependent on cable
length and field bus baud
rate set)
See controller manual
Maximum loading
Positive power supply
(P5V) pin 6 max. 40 mA
Electromagnetic compatibility (EMC)
Resistance to interference
tested as per EN 50082-2
Resistance to suppression
tested as per EN 55011
Limit value severity A *)
*) The fieldbus node FB13-03 can also be used with
individual authorization in residential areas (residen-
tial, business and commercial areas, small firms).
VIFB13 - 03/05 Appendix A
A-6
9701 NH
