2.3 TYPE 05: FITTING THE VALVE TERMINAL
Wall fitting (type 05)
WARNING
With long terminals (e.g. several I/O modules)
use additional supporting brackets every
200 mm. This is to avoid the following:
•
overloading the fastening eyes on the
left-hand end plate
•
the terminal sagging
•
natural resonances
• Proceed as follows:
Calculate the weigh of the terminal
(weigh or estimate).
General rule:
• Make sure that the fastening surface can
carry this weight.
ISO size 1 ISO size 2
Sub-base *)
- 4 valve locations
incl. valves
- 8 valve locations
incl. valves
- 12 valve locations
incl. valves
8 kg
14 kg
20 kg
12 kg
20 kg
28 kg
per node 1 kg 1 kg
per electronic module 0.4 kg 0.4 kg
*) Components for vertical stacking:
Please see pneumatics manual P.BE-ISO-GB
for weights.
VIFB13 - 03/05 2. Fitting
