Calculating the number of inputs/outputs
type 05
Copy the table for further calculations.
Table for calculating the number of inputs/outputs of type 05
INPUTS
1. Number of 4-input modules ______
⋅ 4
2. Number of 8-input modules ______
⋅ 8
3. The 4 status bits are assigned internally
automatically by the terminal. They must be treated
like inputs and must be added to the intermediate sum:
+
+
Total sum of inputs to be configured
OUTPUTS
4. ISO sub-base modules for
• 4 valve locations 8 O
• 8 valve locations 16 O
• 12 valve locations 24 O
5. Number of electronic output modules _______
⋅ 4
=
Total sum of outputs to be configured =
Σ I
4I
Σ I
Σ O
Σ O
Σ O
Σ I
Fig. 4/3: Calculating the number of inputs/outputs for type 05
VIFB13 - 03/05 4. Commissioning
9701 NH 4-9
