Address assignment of the valve terminal
General (types 03 and 05)
The address assignment of the outputs of a
modular valve terminal depends on the number
of valve locations fitted on the terminal. A
distinction must be made between the following
fitting variants:
• valves and digital I/O modules
• valves only
• digital I/O modules only.
The basic rules described below apply to the
address assignment of these fitting variants.
Explicit examples of addressing valve terminals
type 03 and type 05 are described in separate
chapters following these basic rules.
PLEASE NOTE
If one valve location occupies two addresses
the addresses are assigned as follows:
•
lower address
⇒
pilot solenoid coil 14
•
higher address
⇒
pilot solenoid coil 12
VIFB13 - 03/05 4. Commissioning
9701 NH 4-11
