Basic rule 2
If only valves are used, the address assignment
is always as described in basic rule 1.
PLEASE NOTE
•
Maximum 26 solenoid valve coils
can be addressed.
•
There is no rounding up of the last two
positions on the valve side.
•
Valve terminals without input modules do
not require a configuration of inputs.
Status bits are then not available.
Basic rule 3
If only electrical I/Os are used, the address
assignment is always the same as in basic
rule 1.
PLEASE NOTE
•
Counting begins immediately to the left of
the node.
•
There is no rounding up of the last
two positions on the valve side.
VIFB13 - 03/05 4. Commissioning
9701 NH 4-15
