A. Operating the SPC11 in accordance with slave profile 7.4
A-5
Festo P.BE-SPC11-SYS-ASI-EN en 0203NH
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Rese rved Reserved Quit
faults
Start t he
teach
procedure
Accept
the actual
position
as P.04
Accept
the actual
position
as P.03
Move to
the left
Move to
the right
Order Description
Move to the right All the time this bit is set, the drive will move in the direction of the
measuring system zero point.
Move to the left All the time this bit is set, t he drive will move away from the measuring
system zero point.
Accept the actual position
as P.03
When this bit is set (transition from 0 to 1) the current position will be
accepted as the intermediate position P.03.
Accept the actual position
as P.04
When this bit is set (transition from 0 to 1) the current position will be
accepted as the intermediate position P.04.
Start the teach proc edure When this bit is set (transition from 0 to 1) the teach procedure will be
started.
Quit faults When this bit is set (transition from 0 to 1) the current fault will be
quitted.
