A. Operating the SPC11 in accordance with slave profile 7.4
A-7
Festo P.BE-SPC11-SYS-ASI-EN en 0203NH
Read parameter string
Byte Read parameter string
1 Reserved
2 Amplification stage
3 Cushioning stage
4 System parameter
5 Position P.04 high byte *)
6 Position P.04 low byte *)
7 Position P.03 high byte *)
8 Position P.03 low byte *)
9 Position P.02 high byte *)
10 Position P.02 lo w byte *)
11 Position P.01 high byte *)
12 Position P.01 lo w byte *)
13 Actual position high byte *)
14 Actual position low byte *)
*) Position specifications in increments relate d to the max. measur-
ing system length (max. 65536 increments).
