4. Commissioning
4-4
Festo P.BE-SPC11-SYS-ASI -EN en 0203NH
4.1.1 Basic principles of configuring and operating the SPC11
Parameters
The SPC11 must be familiar with certain conditions of use.
Theseconditionsofusearedescribedbythethreefollowing
parameters:
Parameters
Description
Amplification stage Influences the acce leration behaviour of the
drive.
Cushioning stage Influences the retracting behaviour when
moving to the end positions and intermedi-
ate positions.
System parameter Characteristic value for the structure of the
drive.
The parameters can be entered:
– Before commissioning (pre-parametrizing without drive in
the office).
– When commissioning.
