4. Commissioning
4-5
Festo P.BE-SPC11-SYS-ASI-EN en 0203NH
Button functions
The buttons on the SPC11 are only active when the AS-Inter-
face bus cable is not supplied with power or not connected.
The drive c annot be moved until the teach procedure has
successfully been completed.
Key
Description
{/- Reduce the input value or position value.
1)
(The drive moves in the direction of the measuring
system zero point.)
Enter/Teach
(> 2s)
Hold the button pressed down for at least 2 sec-
onds in order to confirm parameter values or to
start the teach procedure.
Esc (< 1s) Press t he button briefly in order to interrupt the
procedure.
+/} Increasetheinputvalueorpositionvalue.
1)
(The
drive moves away from the measuring system zero
point.)
1) Press the button briefly in order to modify the value by 1.
Holdthebuttonpresseddowninordertomodifythevalue
continuously.
WhentheAS-Interfacebuscableisconnectedandpoweris
applied, the buttons of the S PC11 are blocked.
If you use slave p rofile 7.4, you can carry out commissioning
via the AS-Interface bus. Detaile d information on thi s can be
found in Appendix A.
