4. Commissioning
4-12
Festo P.BE-SPC11-SYS-ASI -EN en 0203NH
The display shows the letter A (Amplification stage) and
the stage set (here 02).
(A.02)
If you have activated the modification mode by mistake, you
can abort the procedure by switching off the power supply. If
you have already carried out the teach procedure, you can
hereby avoid the need to carry out this procedure a gain.
With the buttons +/- you can modify the parameter displayed
and transfe r it with Enter (see section 4.2). When the last
parameter has been transferred, the SPC11 then indicates
readiness to carry out the teach procedure (t flashes).
Create status as at deliver y
Prerequisites: The me asuring system must not be connected. The yellow
AS-Interface bus cable must not be connected, as otherwise
the button functions of the SPC11 cannot be used. The com-
pressed air supply must be switched off.
Use the buttons as follows to create the status as at delivery:
1. If necessary, switch off the compressed air and the power
supplies.
2. Disconnect the measuring system cable from the measur-
ing system.
3. Switch on the power supply.
The SPC11 will then show fault E01 (measuring system
not connected...).
(E.01)
