4. Commissioning
4-18
Festo P.BE-SPC11-SYS-ASI -EN en 0203NH
Caution
During the teach procedure, the moveable mass moves at
first slowly , then at the highest possible acceleration and
speed. Make sure that:
– nobody can place his/her hand in the positioning range
of the moveable mass, unless the compressed air supply
is switched off.
– the complete positioning range is free of any objects.
4. If teaching has not yet taken place, the SPC11 indicates
readiness to carry out the teach procedure (t flashes).
(The t flashes.)
Then proceed as described under 5.
If teaching has already taken place, the moveable mass
stands closed-lo op controlled in a taught position
(P.01...P.04) or in any (P...) position. Proceed as follows:
S Hold the Enter/Teach button pressed down for at least
2 seconds. The SPC11 then indicates readiness to
carry out the teach procedure (t flashes).
5. Hold the Enter/Teach button down at least 2 seconds in
order to start the teach procedure.
The SPC11 then carries out the teach procedure. The
moveable mass moves at first slowly, then dynamically.
The display shows the following:
Thedotsflashatthesamerate
The teach procedure can last several minutes, depending on
the drive used. It is concluded when the drive is at end posi-
tion P.01. The display shows the following:
