SERVICE PROCEDURES 103
TO REPLACE THE DVD DRIVE
1. Install the DVD drive in the switch bank assembly.
2. Install the switch bank assembly in the Component Sled, and then install the Component Sled
in the chassis (see page 100).
3. Attach the power and data combination cable to the back of the DVD drive.
Make sure that the other end of the data cable is connected to motherboard connector
SATA 1.
4. If you replaced the DVD drive with a new DVD drive, clear the CMOS as follows:
You need to clear the CMOS after installing a new DVD drive to ensure compatibility
between the new component and the previous settings stored in the BIOS. Make sure the
power cable is removed from the power outlet before clearing the CMOS.
• Remove the battery (see page 84).
• Wait 2 minutes to allow the motherboard electrical components to fully discharge.
• Reinstall the battery.
5. If you installed a new DVD drive and cleared the CMOS, make sure to reset the time and date
in Setup (see Configuration and Setup).
6. Reassemble the E-41 and verify its functionality (see page 104).
