SERVICE PROCEDURES 92
FIGURE 31: E-41 HDD
The HDD is mounted inside a bracket.
If you are replacing the HDD with a new one, you will need:
• The appropriate system software and documentation for the E-41 that you are servicing.
• A compatible version of the user software for the networked computers that will print to
the E-41.
NOTE: Video board
and internal cables are not shown.
HDD
HDD bracket
