The drive required is:
•Present
• Correctly installed
• Not visibly damaged
• Jumpered as the master (secondary) according
to label
• Activity LED lights on power up
DVD drive SATA cable is:
• Firmly connected to motherboard SATA 1
• Not visibly damaged
DVD drive, page 101
Each cable required is:
•Present
• The correct type
• Installed in the correct connector
• Well-seated
• Not visibly damaged (including connectors)
UIB cable, page 48
HDD data cable, page 48
Copier/printer interface cable, page 122
DVD drive power and data combination cable, page 48
Power cable(s), page 122
TABLE 2: Verifying the system
Conditions to verify Part and additional page references
