10

REV. 00 02/01/2015

id.:

SYSTEM DESCRIPTION

2

2.2 COMPONENTS

1 - Operating panel

2 - Display

3 - Keypad

4 - Printer connector

5 - System wiring connector

6 - USB

7 - Buzzer

8 - Printer

9 - Thermal paper roll

3 412

567

8

9
