49
REV. 00 02/01/2015
id.:
CBV ADVANCED MODE FUNCTIONS
3
3.18 VIEWING THE MIXING STATUS
Press key 2
N.B. If the values are displayed in yellow, it means that the mix is not ready yet.
The RPM fi eld may be displayed in three different
colours:
Green: speed is suitable
Yellow: speed is too slow
Red: speed is too fast
Revolutions performed by
the drum during the mixing
phase
Number of revo-
lutions to be per-
formed
Maximum mixing
pressure
Drum rotation
speed
Mixing revolutions
progress
Differential pro-
gress of last mix-
ing revolution
Drum rotation
direction (mix-
ing/ pouring)
3.19 POURING THE MIX
Set the drum rotation in the pouring position; the
following message is displayed
Beginning of the pouring phase has
been detected
when the device detects the end of the pouring phase,
the following message is displayed
End of pouring phase message
Press ESC to return to the recipe page
Number of bags
to be loaded
Number of bags
loaded
The system will indicate the number of bags to be
loaded.
After reaching the number of bags indicated, press OK
and load the material.
