13
REV. 00 02/01/2015
id.:
SYSTEM DESCRIPTION
2
2.4 TECHNICAL FEATURES
Control unit dimensions 160 x 120 x 80 mm
Printer dimensions 120 x 120 x 80 mm
Supply voltage 10 ÷ 35 Vdc
Allowed ambient temperature during the operating phase -20°C) / +60°C
Allowed ambient temperature during the non-operating phase -30°C) / +80°C
Maximum front tilting (Y axis) of the machine during weighing (**) ± 10°
Paper type for printer Thermal
Maximum number of recipes (*) 16
Maximum number of components for each recipe 8
Maximum number of components available in the data storage 32
Languages 9
Selectable unit of measurement kg / lb
Water compensation in the components (*)
Compensation of the machine’s front tilting (Y axis)
during the weighing phase (*) within the ± 10° range
(*) not available in FBC mode
(**) ± 2.5° in FBC mode
