Fiori BATCH CONTROLLER User Manual

74
REV. 00 02/01/2015
id.:
ALARM LIST
5
5.2.1 Alarm table
1 EEPROM memory error
(error in the EEPROM memory)
2 BOOM ANGLE SENSOR NOT CONNECTED OR SHORT TO GND
(the boom angle sensor is disconnected or short circuited to ground)
3 BOOM ANGLE SENSOR SHORT TO Vcc
(the boom angle sensor is disconnected or short circuited to battery voltage)
4
BOTTOM PRESSURE SENSOR NOT CONNECTED OR SHORT TO GND
(the pressure sensor of the boom cylinder bottom is short circuited to
ground)
5 BOTTOM PRESSURE SENSOR SHORT TO Vcc
(the pressure sensor of the boom cylinder bottom is short circuited to
battery voltage)
6 ROD PRESSURE SENSOR NOT CONNECTED OR SHORT TO GND
(the pressure sensor of the boom cylinder rod is short circuited to ground)
7 ROD PRESSURE SENSOR SHORT TO Vcc
(the pressure sensor of the boom cylinder rod is short circuited to battery
voltage)
8 DRUM PRESSURE SENSOR 1 NOT CONNECTED OR SHORT TO GND
(the drum rotation pressure sensor is disconnected or short circuited to
ground)
9 DRUM PRESSURE SENSOR 1 SHORT TO Vcc
(the drum rotation pressure sensor is disconnected or short circuited to
battery voltage)
10 DRUM PRESSURE SENSOR 2 NOT CONNECTED OR SHORT TO GND
(the drum rotation pressure sensor is disconnected or short circuited to
ground)
11 DRUM PRESSURE SENSOR 2 SHORT TO Vcc
(the drum rotation pressure sensor is disconnected or short circuited to
battery voltage)
12 MOISTURE PROBE NOT CONNECTED OR SHORT TO GND
(the moisture sensor is disconnected or short circuited to ground)
13 MOISTURE PROBE SHORT TO Vcc
(the moisture sensor is disconnected or short circuited to battery voltage)
14 FRONTAL TILT SENSOR NOT CONNECTED OR SHORT TO GND
(the front tilting sensor is disconnected or short circuited to ground)
15 FRONTAL TILT SENSOR SHORT TO Vcc
(the front tilting sensor is disconnected or short circuited to battery voltage)
16 LATERAL TILT SENSOR NOT CONNECTED OR SHORT TO GND
(the lateral tilting sensor is disconnected or short circuited to ground)
17 LATERAL TILT SENSOR SHORT TO Vcc
(the lateral tilting sensor is disconnected or short circuited to battery voltage)
Alarm Description Solution
code
• restart the device
• if the problem persists, replace
the device
CHECK THE WIRING CON-
NECTION
• check the connection
• if the problem persists, replace
the sensor
• if the problem persists, replace
the device
