17
REV. 00 02/01/2015
id.:
FBC MODE FUNCTIONS
3
3.9 LOADING COMPONENTS THROUGH WEIGHING
The required engine speed is 2000 revs/min
- Select the desired component
- Load the component into the bucket.
- Withdraw the bucket (A)
- Lift the bucket maintaining a constant speed.
- Repeat the operation until the preset value is reached.
During the fi rst weighing a lower
value has been reached and
therefore the operation
The preset value has been exceeded
The red bar indicates an overload
The following alarm message is displayed:
excessive load
3.11 CANCELLING LAST WEIGHING
If the preset weighing value is exceeded, before pouring the material you may:
Press the indicated key to cancel the weighing, then lower the bucket to pour some material and
repeat the loading operation of the component through weighing.
3.10 LOADING PROGRESS INDICATORS
The loading progress for each individual component is displayed by means of:
- loading progress bar (from 50% to 100%)
- progressive acoustic signal (from 50% to 100%)
A screen will be displayed, in which the user will input
the amount of material to be loaded: the number in
green represents the recipe PRESET, whereas the
number in yellow indicates the total amount of material
to be loaded. Input the desired amount and press OK
to confi rm.
A
