Maintenance Instructions
Seite/Page 102 - Kaptitel/Chapter 6: Maintenance Instructions 22.10.19
6.9.1 Replacement of the fuel filter
Fig. 6.9.1-1: Fuel FilterExchanging the filter, depending upon fuel contamination,
should take place after 300 operational hours at the very
least. The inlet must be clamped, before exchanging the
filter.
Remove the hoses from the used filter and fasten them to the
new filter. The arrow on the filter housing indicates the
direction of the fuel flow. A clogged filter causes a decreased
power output of the generator.
6.9.1.1 Optional fuel filter with sight glass
Fig. 6.9.1.1-1: Fuel filterThe filter change depends on the fuels’ degree of pollution,
but should be executed every 300 operating hours at the
latest.
01. Fuel filter housing
02. Fuel filter element
03. Sight glass
Fig. 6.9.1.1-2: Fuel filter1. Unscrew the housing from its mount (left hand rotation).
