Fischer Panda 7K PMS - Replace the air filter mat; Alternative replacement of the air filter mat with pull out holder

Maintenance Instructions
Seite/Page 104 - Kaptitel/Chapter 6: Maintenance Instructions 22.10.19
6.10.1 Replace the air filter mat
Fig. 6.10-1: Air suction housing1. Open the air suction housing by loosen the six screws on
the housing cover.
Use spanner size 8 mm.
Fig. 6.10-2: Opened air suction housing2. Change the air filter mat.
3. Close the suction air housing.
6.10.2 Alternative replacement of the air filter mat with pull out holder
Fig. 6.10.2-1: Air suction housing with pull out holder 1. Air filter housing with pull out holder.
