Maintenance Instructions
Seite/Page 116 - Kaptitel/Chapter 6: Maintenance Instructions 22.10.19
6.14 Replacing the electric starter
NOTE:Representative procedureThe described procedure is representative for Fischer Panda
generators. The original location of the item must be taken
from the generator description of this manual. All
replacements and repairs should be done by a trained
person.
ATTENTION!Ensure that the generator cannot be started up
accidentally. Remove battery main switch.
For part numbers, refer to the spare parts catalogue.
Fig. 6.14-1: Electric starter1. Open the capsule.
01. Electric starter
Fig. 6.14-2: Electric starter2. Pull off connector.
