Fischer Panda 7K PMS - Jumper for configuration of the Override“ time; Maximum ratings

Remote Control Panel P4 Control
22.10.19 Kapitel/Chapter 9: Remote Control Panel P4 Control - Seite/Page 165
9.5.2 Jumper for configuration of the „Override“ time
1 is standard for „override“ activated
2 is standard for „Override“ deactivated“
9 is standard for „Test mode“
The Test mode is active as long as the button „on/off“ is pressed by turning on the panel.
9.6 Maximum ratings
Operation outside of the maximum ratings can causes damage at the panel and the generator
In not indicated otherwise the ambient temperature is assumed. All voltage data are against GND (X1.2).
Operation voltage U
b
is the voltage at terminator X1.1
J104 J105 J106 Test-Mode Override time [s]
1 open open open no 40
2 closed open open no 20
3 open closed open no 10
4 closed closed open no 5
5 open open closed no 0,16
6 closed open closed no 0,08
7 open closed closed no 0,04
8 closed closed closed no 0,02
9 open open - - yes 2,5
10 closed open - - yes 1,25
11 open closed - - yes 0,63
12 closed closed - - yes 0,31
Parameter Desc. min. max.
Operation Voltage without time limit. full function 10,5 15 V
without time limit, full function (except H-Meter, LED light
lower)
6V
maximal 60 min, Ta = 65 °C, full function 17 V
maximal 60 s, Ta = 65 °C, full function 18 V
maximal 100 ms, Ta = 65 °C, full function 22 V
maximal 100 ms, full function, except H-Meter, some LED
out of ordered
4,5 V
ambient temperature for
operation
0+85°C
capacity of the outputs without time limit 0,25 A
without time limit (1 output only) 0,4 A
External voltage on the
outputs
Outputs with freewheeling diode for short out negative
external voltage
-0,3 Ub V
External Voltage on the
inputs
without time limit. Voltage which are out of the rating will be
short out by the Z- diode.
-0,3 Ub V
Internal F1 Micro fuse 5 x 20 mm glass fuse slow to blow 0,5 A
