Tables
Seite/Page 154 - Kaptitel/Chapter 8: Tables 22.10.19
Fig. 8.3.1.2-1: Engine oil type.
Fig. 8.3.1-2: Temp. range of the SAE classes
8.4 Coolant specifications
Use a mixture of water and antifreeze. The antifreeze needs to be suitable for aluminium. The antifreeze
concentration must be regularly checked in the interests of safety.
Fischer Panda recommend to use the product: GLYSANTIN PROTECT PLUS/G 48
Engine oil type
over 25 °C SAE30 or SAE10W-30; SAE10W-40
0 °C to 25 °C SAE20 or SAE10W-30; SAE10W-40
below 0 °C SAE10W or SAE10W-30; SAE10W-40
Engine coolant automotive industry Product description
Product name GLYSANTIN ® PROTECT PLUS / G48
Chemical nature Monoethylenglycol with inhibitors
Physical form Liquid
Chemical and physical properties
Reserve alkalinity of 10ml ASTM D 1121 13 – 15 ml HCl 01 mol/l
Density, 20 °C DIN 51 757 procedure 4 1,121 – 1,123 g/cm
3
Water content DIN 51 777 part 1 max. 3,5 %
pH-value undiluted 7,1 – 7,3
