Maintenance Instructions
Seite/Page 110 - Kaptitel/Chapter 6: Maintenance Instructions 22.10.19
Fig. 6.11.0-3: Alternator3. The alternator must be pressed in the direction of the
thermostat housing.
4. Exchange the V-belt.
Sample Picture
Fig. 6.11.0-4: V-belt5. Afterwards, the V-belt must be tightened again.
6. The V-belt must be tightened in such a way, that it is
possible to press it about approx. 10 mm.
7. Tighten the screws above and underneath the alternator.
Sample picture
