Maintenance Instructions
Seite/Page 122 - Kaptitel/Chapter 6: Maintenance Instructions 22.10.19
Fig. 6.17-1: FuseFigures similar!
1. Remove the two fixing screws of the plastic cover using a
size 0 or 1 phillips screwdriver.
Reprasentative picture
Fig. 6.17-2: Fuse2. Remove the plastic cover.
Reprasentative picture
Fig. 6.17-3: Fuse3. Using the fuse extraction tool, remove the fuse and
replace it with a new one.
4. To reinstall, reverse the order of steps.
Reprasentative picture
