FISCHER FERITSCOPE DMP30 - Charging the Battery; To Charge the Battery

28
Rechargeable battery FERITSCOPE® DMP30
5.2 Charging the battery
ATTENTION –Make sure the charging power is correct
Whether you use a standard travel charger or an external charger, always make that
the battery is charged to the correct power:
Nominal voltage: 3.8 V=
Nominal capacity: 3880 mA, 14.7 Wh
max. charge voltage: 4.35 V=
max. charge current: 2.4 A
To charge the battery
 Standard – charge the battery using a commercially available charger:
► Do this by inserting the USB-C plug of the charging cable on the top of the
gauge into the USB-C socket under the locking tab.
Battery charging time is approx. 6 h. A green light strip on the switched-off
gauge signals the end of the charging process.
1.
2.
Light strip
USB-C plug of
charging cable
