Measure FERITSCOPE® DMP30
8.5 Measuring in single reading measuring mode - procedure
Measuring on flat specimens - single-tip probe
The display screens should be considered only as examples, the gauge default modes are required here
for the measured reading acquisition, probe D-F-Fe is shown as a typical example of our axial probes
Measuring on cylindrical specimens - single-tip probe
The display screens should be considered only as examples, the gauge default modes are required here
for the measured reading acquisition, probe D-F-Fe is shown as a typical example of our axial probes
