Settings for measurement FERITSCOPE® DMP30
7 Settings for measurement
In order to measure, you need to create and open a batch (measuring file). Settings,
such as those for the measurement procedure are saved in the batch, e.g. specifica-
tion limit monitoring and grouping of measured readings in measurement blocks
during the measurement and in measuring mode. The link to the calibration to which
the measurements are referenced is also stored in the batch file.
If any parameter changes, there is a new measuring application and you have to cre-
ate a new batch.
 A description of the possible batch settings you have to make bef o re a mea-
surement can be found below.
 A description of the batch settings, which you can also make after a measure-
ment, can be found from page 79.
7.1 Creating a new batch
Important Notes
 The ferrite percent specification (Fe%) on the calibration standards was
determined with a round robin based on the metallographic counting method
and is not traceable.
 For measurements in Fe%, the value for ferrite content percentage (Fe%) is
strictly informational and have no reference to traceable standards.
You can create a batch in the following ways:
Create a new batch from scratch
In this case, you must make all the required measurement settings again.
1. > Batches > OK > New > Select a calibration from the list or New from > OK
2. Have you selected a calibration from the list?
- No: Continue with step 3.
- Yes: Continue with step 4.
3. Follow the calibration routine and finish each calibration step via OK. You can also
skip the last calibration step (Std. 2) via , 58.
[ ]
