Required wooden parts
DESCRIPTION REFERENCE
Part 22
Seat Side Left
PLYWOOD SHEET 3
Part 23
Seat Side Right
‒ Gas tank side
PLYWOOD SHEET 3
Part 24
Seat Crossbar
PLYWOOD SHEET 1
Part 25
Seat Crossbar
PLYWOOD SHEET 3
Part 26
Seat Crossbar
PLYWOOD SHEET 3
Part 27
Seat Crossbar Bracket
PLYWOOD SHEET 3
DESCRIPTION REFERENCE
Part 28
Seat Bolster Left
PLYWOOD SHEET 4
Part 29
Seat Bolster Right
PLYWOOD SHEET 4
Part 30
Seat Thigh Bolster Left
PLYWOOD SHEET 4
Part 31
Seat Thigh Bolster Right
PLYWOOD SHEET 4
Part 32
Seat Back
PLYWOOD SHEET 4
Part 33
Seat Bottom
PLYWOOD SHEET 4
Note If you received a 1/4” plywood sheet that is nished on one side and
you intend to paint the Plyy go-kart seat; reverse the wooden parts 28-33
(so the unnished side is outward facing and
ready to receive paint).
