Plywood sheet reference
DESCRIPTION REFERENCE
Sheet 1
3/4” Plywood Sheet
‒ Parts 13
13
Sheet 2
3/4” Plywood Sheet
‒ Parts 14‑18
15 1814
1716
Recommended tools
DESCRIPTION REFERENCE
Dead blow hammer
or mallet
Hammer
Required hardware
№ DESCRIPTION REFERENCE
2 Small Tee Nut
Zinc Plated, 5/16”‑18
P N 12510
12 Spax Screw
#8, 1‑1/2” L
P N 12519
19
