Plywood sheet reference
DESCRIPTION REFERENCE
Sheet 1
3/4” Plywood Sheet
‒ Parts 34
‒ Parts 36‑39
34
38 39
3736
Sheet 3
3/4” Plywood Sheet
‒ Parts 35
35
Recommended tools
DESCRIPTION REFERENCE
Dead blow hammer
or mallet
Hammer
Electric Driver
Required hardware
№ DESCRIPTION REFERENCE
4 Plastic Bushing
Flanged, 1/4” ID, 3/8” OD
P N 125 0 9
8 Spax Screw
#8, 1‑1/2” L
P N 12519
26
8 Pedal Assemblies
