150718 PLYFLY rev A_Steer column | Au gu st 7 , 2 015 5: 06 P M

Plywood sheet reference

DESCRIPTION REFERENCE

Sheet 1

3/4” Plywood Sheet

‒ Part 20

Sheet 2

3/4” Plywood Sheet

‒ Part 19

‒ Part 21

521 19

Recommended tools

DESCRIPTION REFERENCE

Dead blow hammer

or mallet

Hammer

Electric driver

Required hardware

№ DESCRIPTION REFERENCE

4 Small Metal Bushing

Flanged 3/8” ID, 1/4” L

P N 125 38

4 Spax Screw

#8, 1‑1/2” L

P N 12519

Required wooden parts

DESCRIPTION REFERENCE

Part 19

Steering Column Shaft

PLYWOOD SHEET 2

Part 20

Steering Pinion

PLYWOOD SHEET 1

Part 21

Steering Wheel

PLYWOOD SHEET 2

PlyFly Go‑Kart Instruction Guide • 2015 Release
