Required wooden parts

DESCRIPTION REFERENCE

Part 1

Steering Spindle Outer Spacer

PLYWOOD SHEET 1

Part 2

Steering Spindle Outer Spacer

PLYWOOD SHEET 2

Part 3

Steering Spindle Inner Spacer

PLYWOOD SHEET 1

Part 4

Steering Spindle Inner Spacer

PLYWOOD SHEET 1

Part 5

Steering Spindle Bottom Left

PLYWOOD SHEET 2

Part 6

Steering Spindle Bottom Right

PLYWOOD SHEET 1

Part 7

Steering Spindle Top

PLYWOOD SHEET 1

Part 8

Steering Spindle Top

PLYWOOD SHEET 1
