Flatworks plyfly - Plywood Sheet Reference

150718 PLYFLY rev A_Steer rack | Au gus t 5, 20 15 1 0:3 8 PM
Plywood sheet reference
DESCRIPTION REFERENCE
Sheet 1
3/4” Plywood Sheet
‒ Parts 9‑10
109
Sheet 2
3/4” Plywood Sheet
‒ Parts 11‑12
12 11
Recommended tools
DESCRIPTION REFERENCE
Dead blow hammer
or mallet
Hammer
Screwdriver
Electric driver
Required hardware
№ DESCRIPTION REFERENCE
4 Spax Screw
#8, 1‑1/2” L
P N 12519
16
5 Steering Rack Assembly
