Flatworks plyfly - Overview of the Required but Not Provided; Overview of the Required Wooden Parts; Overview of the Required Assemblies

150718 PLYFLY rev A_GoKart | Aug ust 7, 2 015 5 :08 PM
Overview of the required but not provided
DESCRIPTION REFERENCE
Motor Oil
Approximately 1 quart of 10W30 Motor Oil
Gas
Regular unleaded gas.
Overview of the required wooden parts
DESCRIPTION REFERENCE
Part 53
Fairing Left
PLYWOOD SHEET 4
Part 54
Fairing Right
PLYWOOD SHEET 4
Part 55
Fairing Front
PLYWOOD SHEET 4
Overview of the required assemblies
DESCRIPTION REFERENCE
2
Fixed steering column
Assembly
PARTS 13‑18
3
Steering column
Assembly
PARTS 19‑21
4
Seat
Assembly
PARTS 22‑33
5
Gas Pedal
Assembly
PARTS 34, 36‑37
6
Brake Pedal
Assembly
PARTS 35, 38‑39
7
Left Spindle
Assembly
PARTS 1, 3, 5, 7
8
Right Spindle
Assembly
PARTS 2, 4, 6, 8
9
Frame
Assembly
PARTS 21‑28
