List of the wooden assemblies
DESCRIPTION REFERENCE
1
Steering rack
Assembly
Parts 9‑12
2
Fixed steering column
Assembly
Parts 13‑18
3
Steering column
Assembly
Parts 19‑21
4
Seat
Assembly
Parts 22‑33
5
Gas Pedal
Assembly
Parts 34, 36‑37
List of the wooden assemblies
DESCRIPTION REFERENCE
6
Brake Pedal
Assembly
Parts 35, 38‑39
7
Left Spindle
Assembly
Parts 1, 3, 5, 7
8
Right Spindle
Assembly
Parts 2, 4, 6, 8
9
Frame
Assembly
Parts 21‑28
Note If you received a 1/4” plywood sheet that is nished on one side and you
intend to paint the Plyy go-kart seat or fairings; reverse wooden parts 28-33 and
parts 53-55 (so the unnished side is outward facing and ready to receive paint). For
a complete list of wooden parts, go to “List of the wooden parts” on page 62.
