Flatworks plyfly - Part 7: Install the Engine and Drive Train

150718 PLYFLY rev A_GoKart | Aug ust 7, 2 015 5 :08 PM
Chapter 10
6
PART
Recommended tools
DESCRIPTION REFERENCE
Needle Nose Pliers
Allen Wrench
Socket Wrench
Required Assemblies
№ DESCRIPTION REFERENCE
1 Control Cable
1/16” D, throttle & brake control cable
PN 12525
1 Red Throttle Cable
Brake conduit, 5’ L
P N 12527
1 Green Throttle Cable
Gas conduit, 6’ L
P N 1252 8
6 Zip Tie
10lb Nylon, White, 7/8” D, 4” L
P N 125 58
Reference Assemblies
DESCRIPTION REFERENCE
2
Fixed steering
column
Assembly
PARTS 13‑18
5
Gas Pedal
Assembly
Parts 34, 36‑37
6
Brake Pedal
Assembly
Parts 35, 38‑39
9
Frame
Assembly
PARTS 21‑28
48
10 Putting the go‑kart together
