List of loose contents
2.5 HP 4.0 HP 4.0 HP 4.0 HP 4.0 HP
SINGLE WHEEL SINGLE WHEEL SINGLE WHEEL LIVE AXLE LIVE AXLE
№
KIT DESCRIPTION 10” WHEELS 10” WHEELS 12” WHEELS 10” WHEELS 12” WHEELS
12507
Precision Rod
1/4” D, 18” L
1 1 1 1 1
12580
Drive Shaft
Steel, Keyed, 5/8” D, 18” L
SINGLE WHEEL KIT
1 1 1
― ―
12581
Drive Shaft
Steel, Keyed, 5/8” D, 33” L
LIVE AXLE KIT – 10” WHEELS
― ― ―
1
―
12582
Drive Shaft
Steel, Keyed, 5/8” D, 36” L
LIVE AXLE KIT – 12” WHEELS
― ― ― ―
1
12508
Drawer Slide
Hardware included, 10” L
1 1 1 1 1
12517
Green Elastic Cord
3/16” OD, 18” L
1 1 1 1 1
12519
Spax Screw
1 Box, #8, 1‑1/2” L
1 1 1 1 1
12590
10” D Wheels
Rear driven wheel
1 1
―
2
―
12591
10” D Wheels
Undriven wheel
3 3
―
2
―
12592
12” D Wheels
Rear driven wheel
― ―
1
―
2
12593
12” D Wheels
Undriven wheel
― ―
3
―
2
12535
Flatworks Flag
Plyy safety ag
1 1 1 1 1
