Box 3 Contents
2.5 HP 4.0 HP 4.0 HP 4.0 HP 4.0 HP
SINGLE WHEEL
10” WHEELS
SINGLE WHEEL
10” WHEELS
SINGLE WHEEL
12” WHEELS
LIVE AXLE
10” WHEELS
LIVE AXLE
12” WHEELS
DESCRIPTION
Plyy Packaged Hardware Kit Sealed kit of go ‑kart hardware
1 1 1 1 1
Clutch #35 Chain, 11 Tooth Pulley for 5/8” shaft 2.5 HP Model
1
― ― ― ―
Clutch #35 Chain, 12 Tooth Pulley for 3/4” shaft 4.0 HP Model ―
1 1 1 1
Clutch Guard Side Engine Mounting Plate
1 1 1 1 1
Clutch Guard Top Top Cover
1 1 1 1 1
Clutch Guard Cover Outside Cover
1 1 1 1 1
Sprocket 60 Tooth, #35 Chain, 5/8” D bore
1 1 1 1 1
Roller Chain #35 Chain, 29‑5/8” L
1 1 1 1 1
Chain Link For connecting #35 Roller Chain
1 1 1 1 1
Control Cable 1/16” D, throttle & brake control cable
2 2 2 2 2
Red Throttle Cable Brake conduit, 5’ L
1 1 1 1 1
Green Throttle Cable Gas conduit, 6’ L
1 1 1 1 1
VXB Mounted Bearing 5/8” ID
3 3 3 3 3
Brake Caliper
1 1 1 1 1
Brake Disc
1 1 1 1 1
Brake Hub
1 1 1 1 1
Long Hex Bolt Grade 5, 5/8”‑11, 11” L Single Wheel Kit Only
1 1 1
― ―
Short Hex Bolt Grade 5, 5/8”‑11, 6.5” L
4 4 4 4 4
Precision Rod 1/4” D, 18” L
1 1 1 1 1
Drawer Slide Hardware included, 10” L
1 1 1 1 1
Green Elastic Cord 3/16” OD, 18”
1 1 1 1 1
Spax Screw 1 Box,#8 1‑1/2” L
1 1 1 1 1
10” D Wheels Rear driven wheel
1 1
―
2
―
10” D Wheels Undriven wheel
3 3
―
2
―
12” D Wheels Rear driven wheel ― ―
1
―
2
12” D Wheels Undriven wheel ― ―
3
―
2
PlyFly Flag
1 1 1 1 1
For more the complete list of hardware, see List of the packaged contents, on page 70.
5
PlyFly Go‑Kart Instruction Guide • 2015 Release
