Flexim FLUXUS F801 User Manual

15 Libraries FLUXUS ADM 8027, F801, ADM 8127B
UMFLUXUS_F8V4-6-1EN, 2018-10-10 105
15 Libraries
The internal material database of the transmitter contains parameters for pipe and lining materials as well as for fluids. It
can be extended with user defined materials or fluids. User defined materials and fluids will always be displayed in the
scroll lists of the program branch Parameter.
User defined materials and fluids can be stored in an integrated coefficient memory (user area). The coefficient memory
has to be partitioned first (see section 15.1).
The parameters of user defined materials or fluids can be entered as follows:
• as constants without the extended library (see section 15.2)
• as constants or temperature and pressure dependent functions by means of the extended library (see section 15.3)
The material and fluid scroll lists displayed in the program branch Parameter can be arranged (see section 15.5). The
shorter scroll lists make the work more efficient.
15.1 Partitioning of the Coefficient Memory
The coefficient memory can be divided into parts for the following material data:
• material parameters
– transversal and longitudinal sound speed
– typical roughness
• fluid parameters:
– min. and max. sound speed
– kinematic viscosity
–density
For the max. number of data sets for each category of these material data see Tab. 15.1.
Tab. 15.1: Capacity of the coefficient memory
max. number of data sets occupancy of the coefficient memory in %
materials 13 97
fluids 13 97
Select Special Funct.\SYSTEM settings\Libraries\Format USER-AREA.
Press ENTER.
This error message will be displayed if the entered number of data sets for a category of
material data exceeds the capacity of the coefficient memory.
Enter the number of the user defined materials. Press ENTER.
Enter the number of the user defined fluids. Press ENTER.
The occupancy of the coefficient memory is displayed for a few seconds.
Select yes to start the partitioning. Press ENTER.
The coefficient memory is being partitioned. This procedure takes a few seconds.
After the partitioning, Format USER-AREA is displayed again.
Libraries ↕
Format USER-AREA
MAXIMAL: 13!
Materials: 15
Format USER-AREA
Materials: 03
Format USER-AREA
Media: 03
USER AREA:
52% used
Format NOW?
no >YES<
FORMATTING ...
■■■■■■ ...
Libraries ↕
Format USER-AREA
