12 Displaying the Measured Values FLUXUS ADM 8027, F801, ADM 8127B
UMFLUXUS_F8V4-6-1EN, 2018-10-10 83
12 Displaying the Measured Values
The physical quantity is set in the program branch Output Options (see section 12.1).
During the measurement, the designation of the physical quantity is displayed in the upper line, the measured value in the
lower line. The display can be adapted (see section 12.3).
12.1 Selection of the Physical Quantity and of the Unit of Measurement
The following physical quantities can be measured:
• sound speed
• flow velocity: is calculated on the basis of the measured transit time difference
• volumetric flow rate: is calculated by multiplying the flow velocity by the cross-sectional pipe area
• mass flow rate: is calculated by multiplying the volumetric flow rate by the operating density of the fluid
The physical quantity is selected as follows:
Press key BRK to return to the main menu. The further displays of the program branch Output Options are for the acti-
vation of the transmission of measured value.
12.2 Toggling between the Channels
If more than one channel is available/activated, the display for the measured values can be adapted as follows:
• AutoMux mode
– all channels
– only calculation channels
• HumanMux mode
The command →Mux:Auto/Human toggles between the modes (see section 13.1).
12.2.1 AutoMux Mode
In the AutoMux mode, the display and the measuring process are synchronized. The channel on which a measurement is
being made is displayed in the upper line on the left.
The measured values are displayed as configured in the program branch Output Options (see section 12.1). When the
multiplexer switches to the next channel, the display is updated.
The default is the AutoMux mode. The AutoMux mode will be activated after an initialization of the transmitter.
Select the program branch Output Options. Press ENTER.
Select the channel for which the physical quantity is to be entered.
Press ENTER.
This display will not be indicated if the transmitter has only one measuring channel.
Select the physical quantity in the scroll list. Press ENTER.
For the selected physical quantity (except for the sound speed), a scroll list with the avail-
able units of measurement is displayed. The unit of measurement which was selected pre-
viously is displayed first.
Select the unit of measurement of the selected physical quantity. Press ENTER.
Note! If the physical quantity or the unit of measurement is changed, the settings of the outputs will have to
be checked (see chapter 18).
par mea >OPT< sf
Output Options
Output Options ↕
for Channel A:
Physic. Quant. ↕
Volume flow
