Flexim FLUXUS F801 User Manual

FLUXUS ADM 8027, F801, ADM 8127B 13 Advanced Measuring Functions
86 UMFLUXUS_F8V4-6-1EN, 2018-10-10
13 Advanced Measuring Functions
13.1 Command Execution during Measurement
Commands that can be executed during a measurement are shown in the upper line. A command begins with →. If pro-
grammed, a program code has to be entered (see section 13.12).
Press key until the command is displayed. Press ENTER. The following commands are available:
13.2 Damping Factor
Each displayed measured value is a floating average of all measured values of the last x seconds, with x being the damp-
ing factor. A damping factor of 1 s means that the measured values are not averaged because the measuring rate is ap-
prox 1/s. The default value of 10 s is appropriate for normal flow conditions. Values which fluctuate strongly due to of a
higher flow dynamic, require a higher damping factor. Select the program branch Output Options. Press ENTER until
the menu item Damping is displayed.
Press key BRK to return to the main menu.
13.3 Totalizer
total volume or total mass of the fluid at the measuring point can be determined.
There are two flow totalizers, one for the positive flow direction, one for the negative flow direction. The unit of measure-
ment used for totalization corresponds to the volume or mass unit selected for the physical quantity.
The value of a totalizer consists of max. 11 digits, including max. 4 decimal places. For the adjustment of the number of
decimal places see section 17.7.
Tab. 13.1: Executable commands during measurement
command explanation
→Adjust transd.
Select transducer positioning.
If a program code is active, the measurement will be continued 8 s after the last keyboard
entry.
→Clear totalizer
All flow totalizer will be reset to zero.
→Mux:Auto/Human Toggle between the AutoMux and the HumanMux mode of the display (see section 12.2).
This display will not be indicated if the transmitter has only one measuring channel or only
one measuring channel is activated.
→Mux:Nextchan. display the next channel
This display will not be indicated if the transmitter has only one measuring channel or only
one measuring channel is activated.
→Break measure stop the measurement and return to the main menu
→Toggle FastFood
Enter the damping factor. Press ENTER.
S=
A:<>=54 mm!
A: 32.5 m3
54.5 m3/h
A:Mode=FastFood
54.5 m3/h
A:Mode=TransTime
54.5 m3/h
Damping
10 s
