11.3 Other Parameters
11.3.1 Transducer Parameters
If transducers are detected at a measuring channel, the input of parameters will be finished. Press ENTER. The main
menu will be displayed.
If no or special transducers are connected, the transducer parameters have to be entered.
11.3.2 Extension Cable
11.4 Selection of the Channels
The channels on which the measurement is conducted can be activated individually.
• Select a channel with the key .
• Press key to activate or deactivate the selected channel. Press ENTER.
A deactivated channel will be ignored during the measurement. The parameters entered for this channel will remain un-
changed.
If the data logger or the serial interface is activated, the measuring point number has to be entered:
Select Standard to use the standard transducer parameters stored in the transmitter.
Select Special Version to enter the transducer parameters. The transducer parame-
ters have to be provided by the manufacturer.
Press ENTER.
Note! If standard transducer parameters are used, FLEXIM cannot guarantee for the precision of the mea-
sured values. A measurement might even be impossible.
If Special Version is selected, enter the 6 transducer parameters specified by the
manufacturer. Press ENTER after each input.
If the transducer cable is extended, enter the additional cable length (e.g., between the
junction box and the transmitter). Press ENTER.
Select the program branch Measuring. Press ENTER.
If this error message is displayed, the parameters are not complete. Enter the missing pa-
rameters in the program branch Parameter.
The channels for the measurement can be activated and deactivated.
: the channel is active
–: the channel is not active
•: the channel cannot be activated
This display will not be indicated if the transmitter has only one measuring channel.
Note! A channel cannot be activated if the parameters are not valid, e.g., if the parameters in the program
branch Parameter of the channel are not complete.
Enter the measuring point number. Press ENTER.
If arrows are displayed in the lower line on the right, ASCII text can be entered. If no arrows
are displayed, only digits, point and hyphen can be entered.
Transducer Type↕
Standard
Transd. Data 1
35.99
Additional cable
65.0 m
par>MEA<opt sf
Measuring
par>MEA<opt sf
NO DATA!
CHANN:
MEASUR
<
>A< B Y Z
  - .
A:Meas.Point No.:
xxx (↑↓← →)
