FLUXUS ADM 8027, F801, ADM 8127B 18 Outputs
124 UMFLUXUS_F8V4-6-1EN, 2018-10-10
18.1.3 Function Test
The function of the installed output can now be tested. Connect a multimeter to the installed output.
Test of the Analog Outputs
Test of the Binary Outputs
18.2 Error Value Delay
The error value delay is the time interval after which the entered value for the error value is transmitted to the output in
case no valid measured values are available. The error value delay can be entered in the program branch Output Op-
tions if this menu item has previously been activated in the program branch Special Funct.. If the error value delay
is not entered, the damping factor will be used.
Select a list item for the error output. Press ENTER.
If Other value is selected, enter an error value. It has to be within the limits of the output.
Press ENTER.
Note! The settings will be stored at the end of the dialog.
The terminals for the connection of the output are displayed (here: 1- and 2+ for the active
current loop).
Press ENTER.
The current output is tested in the display. Enter a test value. It has to be within the output
range. Press ENTER.
If the multimeter displays the entered value, the output functions correctly.
Select yes to repeat the test, no to return to SYSTEM settings. Press ENTER.
Select Reed-Relay OFF or Open collect OFF in the scroll list Output Test to test
the de-energized state of the output. Press ENTER. Measure the resistance at the output.
The value has to be high ohmic.
Select yes. Press ENTER.
Select Reed-Relay ON or Open collect. ON in the scroll list Output Test to test the
energized state of the output. Press ENTER. Measure the resistance at the output. The val-
ue has to be low ohmic.
Select yes to repeat the test, no to return to SYSTEM settings. Press ENTER.
Select Special Funct.\SYSTEM settings\Dialogs/Menus\Error-val. delay.
Select damping if the damping factor is to be used as the error value delay. Select edit to
activate the menu item Error-val. delay in the program branch Output Options.
From now on, the error value delay can be entered in the program branch Output Op-
tions.
Error-value ↕
Minimum (4.0mA)
I1 active loop
Terminal:1-,2+
I1= 4.0 mA
Again? no >YES<
B1:Output Test ↕
Reed-Relay OFF
B1:Output Test ↕
Reed-Relay ON
Error-val. delay
>DAMPING< edit
