FLUXUS ADM 8027, F801, ADM 8127B 7 Installation of FLUXUS F801
48 UMFLUXUS_F8V4-6-1EN, 2018-10-10
7.9 Sensor Module (SENSPROM)
The sensor module contains important transducer data for the operation of the transmitter with the transducers. It is con-
nected to the connector strips above the display of the transmitter.
If transducers are replaced or added, the sensor module also has to be replaced or added.
• Insert the sensor module into the socket of the measuring channel to which new transducers have to be connected.
Attention! Observe the "Safety Instructions for the Use in Explosive Atmosphere" (see document SIFLUXUS).
Note! The serial number of sensor module and transducer have to be identical. A wrong or incorrectly con-
nected sensor module will lead to incorrect measured values or to a measurement failure.
