14 Data Logger and Transmission of Data FLUXUS ADM 8027, F801, ADM 8127B
UMFLUXUS_F8V4-6-1EN, 2018-10-10 99
Max. 100 series of measured values can be stored. The number of series of measured values depends on the total num-
ber of measured values stored in the previous series of measured values.
The time at which the data logger will be full, will be displayed during the measurement. All activated channels, totalizers
and other values will be considered.
14.2 Transmission of Data
The measured values can be transmitted to a PC via the serial interface RS232 or RS485 (optional).
14.2.1 Online Transmission of Data
The measured values are transmitted during the measurement. The measurement data can be transmitted to a terminal
program.
The data logger works independently of the online transmission.
14.2.2 Offline Transmission of Data
The measurement data of the data logger are transmitted.
Selection of the Serial Interface for the Offline Transmission of Data
Select Special Funct.\SYSTEM settings\serial transmis. Press ENTER until Send Offline via is dis-
played.
14.2.3 Formatting of the Measurement Data
Select Special Funct.\SYSTEM settings\serial transmis.
The type and the serial number of the transmitter is displayed in the upper line.
The available data logger memory will be displayed in the lower line (here: 18 327 addition-
al measured values can be stored). Press key BRK twice to return to the main menu.
Press key to scroll through the display of the upper line.
If the ringbuffer is activated and has overflown at least once, this display will be indicated.
Tab. 14.1: Overview online transmission of data
serial interface transmission of data see
RS-232 terminal program section 14.2.5
RS485 (sender) terminal program section 14.2.5
Note! It is recommended to use the RS485 interface for the online transmission of data. The RS232 inter-
face should only be used if the transmitter does not have an RS485 interface.
Tab. 14.2: Overview offline transmission of data
serial interface transmission of data see
RS-232 terminal program section 14.2.6
RS-232 FluxData section 14.2.7
RS485 (sender) terminal program section 14.2.6
Select the serial interface for the offline transmission.
This display will only be indicated if the transmitter has an RS485 interface.
Select on if the space characters are not to be transmitted. Press ENTER.
The file size will be considerably smaller (shorter transmission time).
X80X -XXXXXXXX
Free: 18327
full= 26.01/07:39
54.5 m3/h
last= 26.01/07:39
54.5 m3/h
Send Offline via
RS232 >RS485<
