Flexim FLUXUS F801 User Manual

FLUXUS ADM 8027, F801, ADM 8127B 14 Data Logger and Transmission of Data
102 UMFLUXUS_F8V4-6-1EN, 2018-10-10
14.2.7 Offline Transmission of Data with the Program FluxData
The measurement data in the data logger are transmitted to a PC via the serial interface RS232 with the FLEXIM program
FluxData.
Settings in the Program
Start the program FluxData V3.0 or higher on the PC.
Select the menu:
Options > Serial interface.
Select the serial interface used from the PC (e.g., COM1).
Click Protocol.
Click OK.
Enter the transmission parameters (see section 14.2.4). If the
default settings of the transmission parameters are to be used,
click Default protocol.
The transmission parameters of FluxData and transmitter have
to be identical.
Click OK.
Transmission of Data
Select the menu:
DUT > Receive measuring values.
Wait until the data are transmitted.

Flexim FLUXUS F801 Specifications

General

Brand	Flexim
Model	FLUXUS F801
Category	Measuring Instruments
Language	English
