The max. flow that the pulse output can work with will be displayed now. This value is calculated on the basis of the en-
tered pulse value and pulse width.
If the flow exceeds this value, the pulse output does not work correctly. In this case, the pulse value and the pulse width
have to be adapted to the flow conditions. Press ENTER.
18.6 Activation of a Binary Output as an Alarm Output
Max. 3 alarm outputs R1, R2, R3 per channel operating independently of each other can be configured. The alarm outputs
can be used to output information on the current measurement or to start and stop pumps, motors, etc.
18.6.1 Alarm Properties
The switching condition, the holding behavior and the switching function of an alarm output can be defined.
Press key to select a scroll list in the upper line. Press key to select a list item in the lower line.
Press ENTER to store the settings.
Select yes to activate the output. Press ENTER.
This error message will be displayed if the flow velocity is selected as the physical quantity.
The use of the pulse output is not possible in this case because integrating the flow velocity
does not result in a reasonable value.
Enter the pulse value. The unit of measurement will be displayed according to the actual
physical quantity.
When the counted physical quantity reaches the introduced pulse value, a pulse will be
transmitted.
Enter the pulse width.
The range of possible pulse widths depends on the specification of the instrument (e.g.,
counter, PLC) that is to be connected to the output.
Note! The menu item Alarm Output will only be displayed in the program branch Output Options if an
alarm output has been installed.
Select in the program branch Output Options the channel for which an alarm output is
to be activated. Press ENTER until the menu item Alarm Output is displayed.
This display will not be indicated if the transmitter has only one measuring channel.
Select yes to activate the alarm output. Press ENTER.
Three scroll lists will be displayed:
• func: switching condition
• typ: holding behavior
• mode: switching function
Pulse Output
B1: no >YES<
Pulse Output
NO COUNTING !
Pulse Value
0.01 m3
Pulse Width
100 ms
Output Options ↕
for Channel A:
Alarm Output
no >YES<
R1=FUNC<typ mode
Function: MAX
