FLUXUS ADM 8027, F801, ADM 8127B A Menu Structure
136 UMFLUXUS_F8V4-6-1EN, 2018-10-10
selection of the sound speed range
auto: The area around the average sound speed is defined by the transmit-
ter.
user: The area around the average sound speed has to be entered.
input of the area around the average sound speed of the fluid
This display will only be indicated if user is selected.
input of the kinematic viscosity of the fluid
range: 0.01...30 000 mm²/s
This display will only be indicated if Other Medium is selected.
input of the operation density of the fluid
range: 0.01...20 g/cm³
This display will only be indicated if Other Medium is selected.
input of the fluid temperature
default: 20 °C
input of the fluid pressure
range: 1...600 bar
This display will only be indicated if Special Funct.\SYSTEM set-
tings\Measuring\Gas-Measuring is activated or if Gas-Measuring is
deactivated and \Special Funct.\SYSTEM settings\Dialogs/Menus
is activated.
selection of the transducer type
This display will only be indicated if no or special transducers are connected.
input of the length of an extension cable
When a calculation channel is selected (Y, Z)
Calculation channels are only available if the transmitter has more than one measuring channel.
display of the current calculation function
selection of the calculation function
Program branch Measuring
main menu: selection of the program branch Measuring
activation of the channels
This display will not be indicated if the transmitter has only one measuring
channel.
input of the measuring point number
This display will only be indicated if Output Options\Store Meas.Data
and/or Serial Output are activated.
activation/deactivation the flow profile correction
This display will only be indicated if Special Funct.\SYSTEM set-
tings\Measuring\Flow Velocity = uncorr. is selected.
INIT-resis-
tant
c-Medium range
auto >USER<
c-Medium=1500m/s
range +-150m/s
Kinem.Viscosity
1.00 mm2/s
Density
1.00 g/cm3
Medium Temperat.
20.0 C
Fluid pressure
1.00 bar
Transducer Type↕
Standard
Additional cable
65.0 m
Calculation:
Y= A - B
>CH1< funct ch2↕
A - B
par >MEA< opt sf
Measuring
CHANN:>A< B Y Z
MEASUR   - .
A:Meas.Point No.:
xxx (↑↓← →)
A:PROFILE CORR.
>NO< yes
